Join companies from around the globe who have discovered our unique and powerful instrumentation database management software products and ISA instrument symbol libraries.



Our software products are being implemented in a variety of industries for the design and management of detailed data associated with power generation, pulp and paper, oil and gas, pharmaceutical, grassroots engineering design and retro-fitting, wastewater treatment facilities, food processing, and batch chemical process facilities.

New! Learn about our customized in-house form integration

Megaflex software includes:

● “ISA-TR20.00.01-2001-2006 Specification Forms for Process Measurement and Control Instruments”

● “ISA-S20-1981 Standard Specification Forms for Process Measurement and Control Instruments, Primary Elements and Control Valves”

● American National Standard, ANSI/ISA-5.1-2024, “Instrumentation and Control Symbols and  Identification”, © Copyright 2024, by ISA–The International Society of Automation.

● Manage data structures for five levels Enterprise, Site, Area, Process Cell and Unit levels in accordance with ANSI/ISA-S88-“Batch Control”. This provides the ability to set up multiple enterprises, set up multiple sites, divide the site into multiple areas, each area can be divided into multiple process cells and each process cell can be divided into multiple units. This allows multiple clients to be managed from a central database structure.

● Universal and Generic form builder provide custom forms to be added and assigned to instrument tag numbers and projects

● Audit activation to enable recording of changes to instrument data sheets after releasing for construction.

● PLC/DCS input/output card configuration interface that provides list of active I/O card loading and spares along with PLC/DCS Tag number referencing.

● Retrieve vendor quotations from past model number devices to enable review of current quotations received.

● Instrument index for managing an instrument’s general information and drawing references.

● Multiple index reports for displaying and printing instrument indexes, I/O configuration reports, available loop numbers, devices grouped by P&ID numbers, quick printing of user selected tags and more.

● Able to denote critical instruments for Environmental, HAZOP, ISO and more and printout their filtered instrument index.

● Document Book for managing engineering drawing titles, file name with links to enable quick access viewing from the instrument index, motor schedule and  mechanical equipment lists.

● Data backup and restore table maintenance.

● User name and password assignment to allow each record to include name of user adding or editing records. Limits access to selected levels for instrument, electrical and mechanical groups.

● Import of data from csv data formats to build instrument index database table.

● Export of data to csv format.

● Motor schedule and motor specification data sheet and linked to instrument index.

● Mechanical equipment list and specification data sheet linked to instrument index.

● Pipe line list linked to instrument index.

● Preventative maintenance module for managing an instruments life cycle. Includes a user interface for logging “As Found” and “As Left” conditions for instrument calibration as well as technician comments, include checkout procedures, link to documents for quick reference, record instrument service and manage instrument service history and more.

● Assign Work Orders reference numbers to instrument maintenance printout associated with software program.

● Task Assignment interface and scheduling

● Electrical motor schedule and specification data sheet

● Mechanical equipment list and specification data sheet

● Piping line list

● Document book for managing drawing numbers, revisions and links to documents for quick viewing from instrument index.

● HART data file interface to import into the database tables

● Preventative maintenance module for managing an instruments life cycle

● Generate instrument loop sheets with AutoCAD using the  “Combo” module

● Construction tracking for device installation, calibration, punch list, commissioning and more using the “Facility Automation” module
